Stainless steel paddle agitator/solvent mixing tank

FOB Reference Price:Get Latest Price
$2,000.00 - $8,000.00 / Sets | 1 Set/Sets juice tank (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Capacity:
50l-20t
Place of Origin:
Shanghai, China
Brand Name:
Gorun
Model Number:
GRST
Dimension(L*W*H):
Customerized
Weight:
50L-20T
Certification:
ISO, TUV, ASME, CCC, SGS, GMP
solvent mixing tank:
paddle agitator mixing tank
HS code:
8479820090
Advantages:
long life
Function:
Widely Used
Usage:
mixing Tank
Product name:
cosmetic, food, beverage, chemical, medicine
Application:
Industry
Test pressure:
0-1Mpa
Standard:
TUV, ISO,CE
Warranty:
1 year, One Year
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
100 Set/Sets per Month juice tank
Packaging & Delivery
Packaging Details
plywood or wooden box for juice tank(HS code: 8479820090)
Port
Shanghai, Qingdao, Tianjin, Lianyungang, Ningbo for juice tank
Lead Time :
Shipped in 5-40 days after payment

Stainless steel paddle agitator/solvent mixing tank:





















































Milk tea production tanks widely used for juice store, mixing, dosing, cooling, heating etc.

Material: SS304/SS316(50L-20,000L)

Details: Interior with mirror polishing; Exterior with matte polishing.

Sturcture: three layer tank with jacket, with agitator, inlet, outlet.

Accessories: sight glass; frequency converter; pressure gauge/sensor; temperature gauge/sensor;

flow sensor; liquid lever gauge; wheels; manual valves/pneumatic valves etc.(Optional)





Mixing Type



G-Scrape type                                        J-Paddle type                                      K-Frame type





RJ-Mulser type                                       RT-Emulsifying head                          CL-Magnetic mixing type





Agitator Selection

Paddle type agitatorMixing speed: 60-80rpm. This series agitator used for mixing low viscosity and concentration medium, Such as: milk, beer, juice etc.
Scrape type agitatorMixing speed: 20-40rpm. This series agitator used for mixing high viscosity medium. Such as: chocolate, honey, mayonnaise etc.
Frame and anchor type agitatorMixing speed: 10-70rpm. This series agitator used for high viscosity medium.

Such  as sediment, oral liquid, etc.

Top mulserMixing speed: 1200-2800rpm. This series agitator used for high viscosity medium homogenizing emulsification. Such as: suspension, oil, fat etc
Bottom emusifying head
Mixing speed: 1200-2800rpm. This series agitator used for high viscosity medium bottom homogenizing. Such as: suspension, oil, fat etc.

Bottom magnetic agitator

with propeller impeller

Mixing speed: 50-800rpm. This type agitator used for mixing thin viscosity, like eyedrop, injection, CIP liquid etc



Gorun Stainless Steel Mixing Tank Series:

Type 1:

Head Type Mixing Tank









Type 2:

mixing+electric heating tank





Introduction




Shanghai Gorun stainless steel mixing tank is made in SS304/SS316 material, total meet in pharmaceutical

grade. The mirror polishing of the internal surface can reach Ra0.38μm, external with matt polishing.



This series tanks are widely used for:

1. Food Industry: Yogurt, Ice Cream, Cheese, Soft Drink, Fruit Jelly, Ketchup, Oil, Syrup, Chocolate etc.

2. Pharmacy Industry: Nutrition liquid, Chinese traditional, Medicine Grease, Biological Products etc.
3. Daily Chemicals: Facial Foam, Hair Gel, Hair Dyes, Toothpaste, Shampoo, Shoe Polish, Cosmestics etc.
4. Chemical Industry: Fat, Dissolvent, Resin, Paint, Pigment, Oil Agent etc.
5. Other Industry: Contruction Industry, Plastic Industry, Textile Industry, Coal Floatation Agent etc.





Company Profile



Shanghai Gorun Machinery Technology Co., Ltd derived from Shanghai Geshi Fluid Equipment Technology Co., Ltd, which is found in1993.

Company has nearly 3000 square meters fully closed filter production workshop which meet GMP requirements.

Our main products

1. stainless steel tank series                                                       2. CIP cleaning system

3. water treatment system                                                           4. stainless steel filter series

5. shell heat exchanger                                                               6. filter cartridge series

7. sanitary pump and other accessories.



Our service

1. Pre-sale service :

Inquires will be replied within the hour. Any questions about products will be answered without any reservation.
Professional quotation will be provided

2. Medium-sale service :

All products will be tested before delivery .
Any updates of logistic information, will feedback to you timely.

3. After-sale service :

Any technical advisory from you will be much appreciated.
One-year product warranty period will be provided, and lifetime technical support. (welcome to contact us anytime.)

Whatsup:+8615921075792

Packing&Delivery


Packing
50L-1500L volume: plywood or wooden box package.
More than 1500L volume: support package.

Delivery

1. By sea: Container/LCL
2. By air: Flight/Express(UPS,FEDEX ,DHL,TNT, EMS, ARAMEX etc)
3. By road



FAQ

Q: Are you a manufacturer or a trader?
We're a manufacturer with more than 20 years professional production experience.

Q: Can you provide us the design drawing?

Yeah, of course, we will provide you the drawing after you payment or prepaid.



Q: Can your factory produce products according to our drawings?
Yes, we can. Most products can be customized, including the Logo on products.

Q: What kind of your packaging ?
Neutral plywood or wooden box packaging or according to customer’s requirements.

Q: How long is your delivery time?
Normally 10-45days after payment, and we promise we will delivery as soon as we can.



Contact us

Mail: gy AT shgorun.com                                                       Cell: +86-15921075792
Tel: +86-021-5922 8528                                                         Fax: +86-021-5922 8085
Add: No.8 Tianyi Road, Qingpu, Shanghai, China
